    Hohlraumboden

Floor construction

Hollow Flooring, Multiple Socket Connection Units, Floor Heating, Navifloor, Synthetic Resin Concrete, Thin Compensation D800, Thin Compensation Type S111, Vitmolit, Vitmopox, Concrete/Screeds

For quick and tolerance-levelling subfloor levelling BARiT offers a resin-bonded concrete.

Resin-bonded concrete can offset strong differentials in heights and bridge strong tolerances. With the requirement to compensate for slopes and for lining the subfloor to + / - 0 mm, EP-RESIN-CONCRETE can be installed to cover and compensate for the highest point.

Quick Info

  • planar
  • height adjustment
  • quick readiness
  • low-shrink

Properties

BARiT EP-RESIN-CONCRETE is an epoxy resin adhesive bridge installed as a composite. The shrink-free BARiT EP-RESIN-CONCRETE can also offset holes, ridges, etc. and allows for layers from 0 - 250 mm thick.
BARiT RESIN-CONCRETE is composed of quartz granules, gravel and is tied together by a solvent-free, epoxy resin. BARiT EP-RESIN-CONCRETE is free of shrinkage, ready for additional structural work after 8 hours and is resilient after 24 hours.

Type SYNTHETIC RESIN CONCRETE
Fields of use Remodeling new buildings
Suitability rapid compensation to 0 mm
Basic raw-material Epoxy with quarzgranulat
Binding agent Epoxy resin
Fillers/pigments -
Application thickness 0 to 250 mm
Own weight 2 kg/m²
Technical properties Epoxy bound
Resistance to pressure DIN 1164** > 40 N/mm²
Bending tensile strength DIN 1164** -
Processing manual mixing and application
Environmental compatibility free from harmful substances and poison, fully recyclability
Use Indoor
Curing time at 20°C
  • ready for application
  • ready for use

  • after 12 hours
  • after 24 hours
** with prism method
